● Continuous flow settings up to 2.0 LPM

● Pulse flow settings 1-10

● Suitable for use at home, at work or on the go. It weighs just 7.4 pounds with battery installed.

● Energy Smart Technology®

● Equipped with DNA Technology® Device Connectivity Platform

Main Features:

• Includes multifunction carry bag for ease of mobility

• Vehicle performance with DC power on all settings

• Meets FAA requirements for air travel

• Color LCD screen with easy-to-use control panel for quick set-up in hospital, clinic or home

• Compact, innovative and easily accessible battery design that is chargeable on all settings while in use

• Performance monitoring and proactive support available through proprietary Dynamic Network Analysis® (DNA) Technology.

• WARRANTY3 Years - Review manufacturer's documentation for full warranty details.

 FAA APPROVED

• FAA Compliant Label Included on Base of Unit for Easy Identification. This product meets FAA regulations for use on commercial flights within the US and all international flights that depart or arrive in the US. Click here for TSA / FAA information on traveling with sleep and oxygen therapy. Always contact your airline prior to your flight to confirm any requirements they may have (i.e. a copy of your prescription or a letter of medical necessity) for allowing your device on board.

PHYSICAL SPECIFICATIONS

• SIZE (APPROX)10 x 9 x 3.5 Inches

• WEIGHT (APPROX) 6.36 Lbs. (7.5 Lbs with Battery)

• DISPLAY TYPE: Color LCD

OXYGEN PERFORMANCE SPECIFICATIONS

• CONTINUOUS SETTINGS: 0.5 to 2.0 LPM

• PULSE DOSE SETTINGS: 1 to 10 LPM

• OXYGEN PER PULSE: 8 to 80 mL (Average Bolus Size)

• OXYGEN CONCENTRATION: 87% - 95% at Sea Level at All Settings

• START UP / WARM UP: 5 Minutes

• SOUND LEVELS: ~ 44.4 dBa (at Pulse Setting 2); ~ 52.3 dBa (at Maximum Settings) (Typical)

• OPERATING ALTITUDE: Up to 13,123 Feet

• TUBING & CANNULA LENGTH: Up to 7 Feet in Pulse Mode. Up to 50 Feet in Continuous Flow Mode (Maximum)

• FILTERS: Intake Filter

• ALARM goes off for: Low Purity, Low Battery, Low External Power, Unauthorized Battery, Over Temperature, Invalid Motor Temperature, Invalid Box Temperature, Invalid Flow, No Flow.

POWER SPECIFICATIONS

• AC (WALL) POWER100-240VAC, 50/60Hz @ 2.5amps

• AC POWER Supplies

• AC POWER SUPPLY SIZE: 7.00 x 2.50 x 0.75 Inches (Approx)

• AC POWER SUPPLY WEIGHT: 1.9 Lbs (Approx)

• AC POWER CORD LENGTH: 9 Feet 6 Inches (Approx)

• POWER CONSUMPTION: 150W (Maximum)

• DC POWER SUPPLY WEIGHT: 0.39 Lbs (Approx)

• DC POWER INPUT: 11.5 - 15V, 10A

• DC POWER CONSUMPTION120W (Maximum)

BATTERY SPECIFICATIONS

• BATTERY TYPE: Lithium Ion

• BATTERY SIZE: 3.4 x 3.6 x 1.5 Inches (Approx)

• BATTERY WEIGHT: 1.14 Lbs (Approx)

• • BATTERY RUN TIME
    • Setting 0.5 = 3.25 Hrs Continuous
      Setting 1.0 = 4.50 Hrs Pulse; 2.00 Hrs Continuous
      Setting 2.0 = 4.00 Hrs Pulse; 1.00 Hrs Continuous
      Setting 3.0 = 3.50 Hrs Pulse
      Setting 4.0 = 3.00 Hrs Pulse
      Setting 5.0 = 2.50 Hrs Pulse
      Setting 6.0 = 2.00 Hrs Pulse
      Setting 7.0 = 1.75 Hrs Pulse
      Setting 8.0 = 1.75 Hrs Pulse
      Setting 9.0 = 1.25 Hrs Pulse
      Setting 10.0 = 1.25 Hrs Pulse (Average)

• RECHARGE TIME: Under 2.5 Hours (Typical Per Battery)

To Maximize Battery Life: Store battery in a cool, dry place when not in use. Store battery with at least 50% capacity remaining. If using multiple batteries, uniquely label each battery to ensure each battery is rotated equally. Charge batteries every three (3) months when not in use.
